ASUS 1700 PRO WS W680M-ACE SE M-ATX

NewBrand new, not previously used.

Product code: 130344

£517.75In stock

In stock

  • Questions? Call 01905 673738 – you'll talk to the person who builds them
  • Collect from our Worcester shop, open 7 days
  • Free UK delivery on this item
ShareFacebookWhatsAppEmail
Specifications & details

ASUS PRO WS W680M-ACE SE (Socket 1700/W680/DDR5/S-ATA 6Gb/s/Micro ATX)

Specifications

Model Number PRO WS W680M-ACE SE
Warranty 3 Years
BIOS 256 Mb Flash ROM, UEFI AMI BIOS
Chipset Intel W680
CPU Socket 1700
CPU Interface Socket 1700
CPU Support https://www.asus.com/uk/motherboards-components/motherboards/workstation/pro-ws-w680m-ace-se/helpdesk_qvl_cpu?model2Name=Pro-WS-W680M-ACE-SE
Memory Total Slots 4
Memory Type DDR5
Slot Type 1 x PCIe 5.0 x16‚1 x PCIe 4.0 x4‚1 x PCIe 3.0 x1
S-ATA Controller 4
RAID Raid 0/1/5/10
M.2 Connector 2 x PCIe Gen 4.0 x4
On-Board LAN 2 x Intel 2.5Gb Ethernet‚1 x Realtek 1Gb Ethernet dedicated for AST2600‚ASUS LANGuard
On-Board Audio Realtek 7.1 Surround Sound High Definition Audio CODEC
On-Board Video Processor with integrated graphics is required
Back Panel I/O Ports 2 x USB 3.2 Gen 2 ports (1 x Type-A, 1 x Type-C®)‚4 x USB 3.2 Gen 1 ports (4 x Type-A)‚1 x DisplayPort‚1 x HDMI port‚1 x VGA port from AST2600‚2 x Intel 2.5Gb Ethernet ports‚1 x Realtek 1Gb Ethernet dedicated for AST2600‚3 x Audio jacks‚1 x BIOS Flashback button
Internal I/O Connectors Fan and Cooling related‚1 x 4-pin CPU Fan header‚1 x 4-pin CPU OPT Fan header‚1 x 4-pin W_PUMP+ header‚3 x 4-pin Chassis Fan headers‚Power related‚1 x 24-pin Main Power connector‚1 x 8-pin +12V Power connector‚Storage related‚2 x M.2 slots (Key M)‚4 x SATA 6Gb/s ports‚1 x SlimSAS port‚USB‚1 x USB 3.2 Gen 2×2 connector (supports USB Type-C)‚1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports‚2 x USB 2.0 headers support 4 additional USB 2.0 ports‚Miscellaneous‚1 x LPT header‚1 x T-sensor‚1 x Clear CMOS header‚1 x COM Port header‚1 x Front Panel Audio header (AAFP)‚1 x SPI TPM header (14-1pin)‚1 x 20-3 pin System Panel header with Chassis intrude function‚BMC Related‚1 x BMC LED and switch‚1 x VGA switch1 x BMC LAN fixed IP switch‚1 x IPMI switch‚1 x Q_PSU switch‚1 x PSU SMBus header‚1 x VPP_I2C header‚1 x Micro SD card socket‚1 x BMC_T_SENSOR header‚1 x Location button header‚1 x Location LED and header‚1 x Message LED and header
Form Factor Micro ATX
Product Width 244mm
Product Length 244mm
Special Features Intel LGA 1700 socket: Ready for 13th Gen Intel Core processors and 12th Gen Intel Core Processors.‚Enhanced power solution: DrMOS, ProCool connector, alloy chokes and durable capacitors for stable power delivery.‚Next-gen connectivity: PCIe 5.0 Safeslot, 2 x M.2 PCIe 4.0, SlimSAS, dual Intel 2.5Gb Ethernet, front panel USB 3.2 Gen2x2 Type-C, TPM header.‚Server-grade IPMI remote management: Hardware and software-level with a dedicated LAN port link to AST2600 BMC controller, plus a real-time monitoring and management software – ASUS Control Centre Express.‚Comprehensive cooling: VRM heatsink, M.2 heatsinks, hybrid fan headers and Fan Xpert 4.‚Trusted stability: Highly compatible with the latest technologies with solid QVL list and tested for 24/7 operation, validated for extensive compatibility.
Keywords Motherboard‚M-ATX‚1700
