ASUS 1700 PRO WS W680-ACE IPMI - photo coming soon

ASUS

ASUS 1700 PRO WS W680-ACE IPMI

NewBrand new, not previously used.

Product code: 130343

£554.41Only 5 left

In stock

  • Questions? Call 01905 673738 – you'll talk to the person who builds them
  • Collect from our Worcester shop, open 7 days
  • Free UK delivery on this item
ShareFacebookWhatsAppEmail
Specifications & details

ASUS PRO WS W680-ACE IPMI (Socket 1700/W680/DDR5/S-ATA 6Gb/s/ATX)

Specifications

Model Number PRO WS W680-ACE IPMI
Warranty 3 Years
BIOS 256 Mb Flash ROM, UEFI AMI BIOS
Chipset Intel W680
CPU Interface Socket 1700
CPU Support https://www.asus.com/uk/motherboards-components/motherboards/workstation/pro-ws-w680-ace-ipmi/helpdesk_qvl_cpu?model2Name=Pro-WS-W680-ACE-IPMI
Memory Total Slots 4
Memory Type DDR5
Slot Type 2 x PCIe 5.0 x16 slots‚2 x PCIe 3.0 x16 slots (supports x4 mode)‚1 x PCIe 3.0 x1 slot
S-ATA Controller 8
SAS Controller 1 x SlimSAS
M.2 Connector 3 x PCIe Gen 4.0 x4
On-Board LAN 2 x Intel 2.5Gb Ethernet‚ASUS LANGuard
On-Board Audio Realtek 7.1 Surround Sound High Definition Audio CODEC
On-Board Video Processor with integrated graphics is required
Back Panel I/O Ports 2 x USB 3.2 Gen 2 ports (1 x Type-A, 1 x Type-C)‚4 x USB 3.2 Gen 1 ports (4 x Type-A)‚2 x USB 2.0 ports (2 x Type-A)‚1 x DisplayPort‚1 x HDMI port‚1 x VGA port‚2 x Intel 2.5Gb Ethernet ports‚5 x Audio jacks‚1 x BIOS Flashback button
Internal I/O Connectors Fan and Cooling related‚1 x 4-pin CPU Fan header‚1 x 4-pin CPU OPT Fan header‚1 x 4-pin W_PUMP+ header‚3 x 4-pin Chassis Fan headers‚Power related‚1 x 24-pin Main Power connector‚1 x 8-pin +12V Power connector‚1 x 4-pin +12V Power connector‚1 x 6-pin PCIe Power connector‚Storage related‚3 x M.2 slots (Key M)‚4 x SATA 6Gb/s ports‚1 x SlimSAS port‚USB‚1 x USB 3.2 Gen 2×2 connector (supports USB Type-C)‚1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports‚2 x USB 2.0 headers support 4 additional USB 2.0 ports‚Miscellaneous‚1 x LPT header‚1 x T-sensor‚1 x Clear CMOS header‚1 x COM Port header‚1 x BMC Header‚1 x Front Panel Audio header (AAFP)‚1 x Start button‚1 x Flexkey button‚1 x SPI TPM header (14-1pin)‚1 x 20-3 pin System Panel header with Chassis intrude function‚1 x M.2 slot (Key E)‚1 x LPT_P80 Switch‚1 x Thunderbolt header
Form Factor Standard ATX
Product Width 244mm
Product Length 305mm
Special Features Intel LGA 1700 socket: Ready for 13th Gen Intel Core processors and 12th Gen Intel Core, Pentium Gold and Celeron Processors.‚Bundle with IPMI expansion card: Equips with a dedicated Ethernet controller to BMC chip to provide the intelligence for its IPMI architecture.‚Enhanced power solution: DrMOS, ProCool connector, alloy chokes and durable capacitors for stable power delivery.‚Next-gen connectivity: Dual PCIe 5.0 SafeSlots, dual PCIe 3.0 slots, 3 x M.2 PCIe 4.0, SlimSAS, dual Intel 2.5Gb Ethernet, front panel USB 3.2 Gen2x2 Type-C, Thunderbolt 4 header support, TPM header, LPT header.‚Comprehensive cooling: Large VRM heatsink, M.2 heatsinks, hybrid fan headers and Fan Xpert 4.‚Advanced security management: USB port management, software blacklisting and Regedit on/off controls via ASUS Control Centre Express.‚Trusted stability: Tested for 24/7 operation, validated for extensive compatibility and equipped with SafeSlot and SafeDIMM for enhanced durability.
Keywords Motherboard‚1700‚W680
