J5CREATE DUAL HDMI VIDEO CAPTURE

Product Name: J5Create Dual HDMI Video Capture

Web Address: en.j5create.com

Model Number: JVA06-N

EAN: 4712795085563

Package Type: Retail

Warranty: 2 Years

Colour: Black

Enclosure: Aluminium

Host Connector: 1 x USB-C Male

Ports: 1 x USB-C 3.0 (host)‚1 x USB-C 3.0 (power)‚2 x HDMI input‚1 x HDMI output‚1 x Mic in‚1 x Speaker out‚2 x Cold shoes

Audio Input: HDMI or 3.5 mm Mic in

Audio Output: HDMI or 3.5 mm Speaker out

Video Input: 2 x HDMI Female

Video Output: 1 x HDMI Female

Power Source: Bus-powered or self-powered (USB-C PD power)

Audio Channel: 2.1 via HDMI

Audio Frequency: 48kHz

Compressions: USB 2.0: MJPEG‚USB 3.0: YUV 4:2:2

Format: USB 3.0: YUV 4:2:2‚USB 2.0: MJPEG

Headset: 40 mW output power into 16O at 3.3V‚THD -75 dB at 20 mW

Microphone: Stereo microphone supported‚24-bit sigma-delta AD

Max Display Refresh Rate: 60Hz

Supported Resolution – Input: Progressive:‚1920 x 1080p at 24/25/30/50/60‚1680 x 1050p at 60‚1600 x 1200p/900p at 60‚1440 x 900p at 60‚1400 x 1050p at 60‚1366 x 768p at 60‚1360 x 768p at 60‚1280 x 1024p/800p/720p at 60‚1024 x 768p at 60‚800 x 600p at 60‚720 x 576p/480p at 60‚640 x 480p at 60‚Interlace:‚1920 x 1080i at 50/60‚720 x 576i at 50‚720 x 480i at 60

Supported Resolution – Output: 1920 x 1080p at 60‚1280 x 720p at 60‚720 x 576p at 50‚720 x 480p at 60‚640 x 480p at 60

Power: Input Current: Up to 3A‚Input Voltage: Up to 20V‚Output Current: Up to 3A‚Output Voltage: Up to 20V‚Power Consumption: ? 1000mA‚Power Delivery: Up to 60W via USB-C

Cable Length: USB-C to USB-C: 60cm‚USB-C to USB Type-A: 60cm

Humidity: < 85% non-condensing

Temperature: Operating: 0 to 45°C‚Storage: -10 to 65°C

Product Width: 134.6mm

Product Length: 63.7mm

Product Height: 18.4mm

Product Weight: 172g

Package Width: 9.5cm

Package Length: 15.5cm

Package Height: 7cm

Gross Weight: 0.42Kg

Special Features: Dual HDMI input for capturing 2 channels.‚Full HD video and audio high performance record/playback through USB-C 3.1 Gen1.‚Uncompressed 1080p at 60 FPS capture via HDMI 1.3a.‚Supports 1080p 60 HDMI loop out (PGM out).‚6 screen mode configurations with PIP (Picture in Picture) and PBP (Picture by Picture).‚Easily switch between different screen modes and adjust transition effects with the built-in buttons.‚Directly activate Chroma Key features through the built-in controls.‚Adjustable segmented window arrangements in PBP (Picture by Picture) mode.‚Flexible audio connection via HDMI or add external audio with 3.5 mm mic-in and speaker out audio jack.‚3 individual audio mixer on/off switches supported.‚3 channel volume indicators.‚Easy DSLR attachment with 2 cold shoe adapters (included).‚Supports USB-C Power Delivery 3.0.‚UVC standard, plug and play.‚LED activity indicator: HDMI IN. / USB Link. / Volume Unit.

Package Contents: 1 x JVA06 Dual HDMI Video Capture‚1 x Quick Installation Guide (QIG)‚1 x USB-C 2.0 to USB-C cable‚1 x USB-C 3.0 to USB Type-A cable‚1 x 100cm HDMI cable

Keywords: Capture‚HDMI‚USB-C‚1080p
