ASUS SP5 RS521A-E12-RS24U 2U SERVER

Product Name: ASUS RS521A-E12-RS24U Rackmount 2U Server (Socket SP5/DDR5)

Web Address: www.asus.com

Model Number: RS521A-E12-RS24U/1G/2kW/16NVMe/FAN/RH/OCP/GPU

EAN: 4711387866177

UPC: 197105866171

Package Type: Retail

Warranty: 3 Years

CPU Interface: 1 x Socket SP5

CPU Support: https://servers.asus.com/products/servers/rack-servers/rs521a-e12-rs24U#Resources

Memory Total Slots: 24

Memory Capacity: 3072GB

Memory Type: with AMD EPYC 9005 series processors‚DDR5 6400/5600 RDIMM/3DS RDIMM‚with AMD EPYC 9004 series processors‚DDR5 4800 RDIMM/ 3DS RDIMM

Slot Type: Up to 1 PCIe Gen5 slots + 1 OCP3.0‚1 x PCIe Gen5 x8, LP‚1 x OCP 3.0 Slot ( (PCIe Gen5 x16)

Drive Bays Internal 2.5": 24 NVMe configuration SKU:‚24 x 2.5” hot-swap drive bays‚Support 24x NVMe‚Rear bays:2 x 2.5” SATA hot-swap drive bay

M.2 Connector: 2

On-Board LAN: 1 x Dual Port Intel I350-AM2 GbE LAN Controller‚1 x Management Port

Front I/O: 2 x USB 3.2 Gen1 ports

Back Panel I/O Ports: 2 x USB 3.2 Gen1 ports‚1 x VGA port‚1 x Management port‚2 x 1GbE LAN ports

Switch/LED: Front:‚1 x Power Button/LED‚1 x Reset Switch‚1 x Location Button/LED‚1 x HDD Access LED‚1 x Message LED‚LAN 1-2 LED‚Rear:‚1 x Port80 LED (Q-Code)‚1 x Power Button/LED‚1 x Location Button/LED‚1 x Message LED

Management Solution: ASUS Control Center‚ASUS ASMB11-iKVM (on-board)

Environment: Operating temperature: 10°C – 35°C‚Non operating temperature: -40°C – 70°C‚Non operating humidity: 20% – 90% (Non condensing)

PSU: 1+1 Redundant 2000W/1600W 80 PLUS Titanium‚Power Supply

Form Factor: 2U

Product Width: 449mm

Product Length: 840mm

Product Height: 88.1mm

Package Width: 58.5cm

Package Length: 110.3cm

Package Height: 29.55m

Gross Weight: 26.13Kg

Special Features: Powerful performance: Powered by AMD EPYC 9005 processors with 192 Zen 5c cores, 12-channel, up to 5200 MHz DDR5 and support for a maximum TDP of up to 360 watts.‚Scale-up storage and expansion design: Up to 24 all-flash NVMe drives on the front panel, two drives in the real panel, and 5 PCIe 5.0 slots for higher bandwidth and system upgrade.‚Flexible networking module design: On-board LAN module, and OCP 3.0 module with PCIe 5.0 slot in rear panel for faster connectivity.‚Air cooling solution: With heatsink achieves lower power-usage effectiveness (PUE) and optimized TCO for data centres for versatile workloads.‚Enhanced IT-infrastructure management: ASUS ASMB11-iKVM remote control with ASPEED AST2600, ASUS Control Centre IT management software and hardware-level Root-of-Trust solution.‚Read for AI and HPC workloads: Up to two dual-slot GPUs, including NVIDIA A100 and A40, AMD Instinct and Xilinx.

Package Contents: 2U Rackmount System

Keywords: 2U‚Rackmount‚System
