AORUS 1700 Z790 AORUS ELITE AX

Product Name: Aorus Z790 AORUS ELITE AX (Socket 1700/Z790/DDR5/S-ATA 6Gb/s/ATX)

Web Address: www.gigabyte.com

Model Number: Z790 AORUS ELITE AX

EAN: 4719331849467

UPC: 889523034002

Package Type: Retail

Warranty: 3 Years

BIOS: 1 x 256 Mbit flash‚Use of licensed AMI UEFI BIOS‚PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Chipset: Intel Z790 Express

CPU Interface: Socket 1700

CPU Support: https://www.gigabyte.com/Motherboard/Z790-AORUS-ELITE-AX-rev-10/support#support-cpu

RAM Technology: DDR5 (Dual Channel)

RAM Slots: 4 x 288-pin

RAM Speeds: Up to DDR5 7600 (O.C.)

Max. Memory Support: 128GB

PCI Express 4.0 x16: 2

PCI Express 5.0 x16: 1

S-ATA 6Gb/s Port(s): 6

RAID: Raid 0/1/5/10

M.2 Socket(s): 3 x PCIe Gen 4.0 x4‚1 x PCIe Gen 4.0 x4/SATA

On-Board LAN: Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)

Wireless NIC: Wi-Fi 6E

Wireless Technology: WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands‚Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate

Bluetooth: v5.3

On-Board Audio: Realtek Audio CODEC

On-Board Video: Processor with integrated graphics is required

Back USB 2.0 Port(s): 4

Back USB 3.2 Port(s) Type-A Gen 1: 3

Back USB 3.2 Port(s) Type-A Gen 2: 2

Back USB 3.2 Port(s) Type-C Gen 2×2: 1

Back HDMI Port(s): 1

Back DisplayPort(s): 1

Back LAN Port(s): 1

Back Audio Jack(s): 2

Back S/PDIF Output Port(s): 1

Back Other Port(s): 2 x SMA antenna connectors (2T2R)

24-pin ATX Power: 1

8-pin ATX Power: 2

USB 2.0 Header(s): 2

USB 3.2 Header(s) Gen 1: 1

USB 3.2 Header(s) Gen 2: 1

Thunderbolt AIC Connector(s): 1

Front Panel Audio Connector: 1

TPM Header(s): 1

Internal Other Port(s): 2 x Addressable LED Strip Headers‚2 x RGB LED Strip Headers

Internal Button(s): 1 x Reset‚1 x Q-Flash Plus‚1 x Clear CMOS‚1 x Reset Jumper‚1 x Clear CMOS Jumper

Form Factor: Standard ATX

Product Width: 244mm

Product Length: 305mm

Package Width: 27cm

Package Length: 34cm

Package Height: 8cm

Gross Weight: 2.05Kg

Special Features: Intel Socket LGA 1700: Support 13th and 12th Gen Series Processors.‚Unparalleled Performance: Twin 16+1+2 Phases Digital VRM Solution.‚Dual Channel DDR5: 4 x SMD DIMMs with XMP 3.0 Memory Module Support.‚Next Generation Storage: 4 x PCIe 4.0 x4 M.2 Connectors.‚Advanced Thermal Design and M.2 Thermal Guard III: To Ensure VRM Power Stability and M.2 SSD Performance.‚EZ-Latch Plus: M.2 Connectors with Quick Release and Screwless Design.‚Fast Networks: 2.5GbE LAN and Wi-Fi 6E 802.11ax.‚Extended Connectivity: DP, HDMI, Front USB-C 10Gb/s, Rear USB-C 20Gb/s.‚Smart Fan 6: Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP.‚Q-Flash Plus: Update BIOS Without Installing the CPU, Memory and Graphics Card.

Package Contents: Motherboard‚Manual‚1 x Antenna‚2 x SATA Cables‚1 x G Connector

Keywords: Motherboard‚1700‚Z790‚DDR5‚WiFi‚Bluetooth
