GIGABYTE AM4 B550 X GAMING WIFI7 - photo coming soon

Gigabyte

GIGABYTE AM4 B550 X GAMING WIFI7

NewBrand new, not previously used.

Product code: 130532

£133.21In stock

In stock

  • Questions? Call 01905 673738 – you'll talk to the person who builds them
  • Collect from our Worcester shop, open 7 days
  • Free UK delivery on orders over £500 – add £366.79 more to qualify
ShareFacebookWhatsAppEmail
Specifications & details

Gigabyte B550 X Gaming WIFI7 (Socket AM4/B550/DDR4/S-ATA 6Gb/s/ATX)

Specifications

Model Number B550 X GAMING WIFI7
Warranty 3 Years
BIOS 1 x 128 Mbit flash‚Use of licensed AMI UEFI BIOS‚PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Chipset AMD B550
CPU Interface Socket AM4
CPU Support https://www.gigabyte.com/Motherboard/B550-X-GAMING-WIFI7-rev-1x/support#Support-Cpu-Support
RAM Technology DDR4 (Dual Channel)
RAM Slots 4 x 288-pin
RAM Speeds Up to DDR4 3200
Max. Memory Support 128GB
PCI Express 3.0 x16 1
PCI Express 4.0 x16 1
PCI Express 3.0 x1 2
S-ATA 6Gb/s Port(s) 4
RAID Raid 0/1/10
M.2 Socket(s) 1 x PCIe Gen 4.0 x4/SATA‚1 x PCIe Gen 3.0 x4/SATA
LAN Speed Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Wireless NIC Wi-Fi 7
Wireless Technology 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands
Bluetooth v5.4
On-Board Audio Realtek Audio CODEC‚High Definition Audio‚2/4/5.1/7.1-channel
On-Board Video Processor with integrated graphics is required
Back USB 2.0 Port(s) 2
Back USB 3.2 Port(s) Type-A Gen 1 3
Back USB 3.2 Port(s) Type-A Gen 2 1
Back USB4 Port(s) Type-C 1
Back HDMI Port(s) 1
Back DisplayPort(s) 1
Back LAN Port(s) 1
Back Audio Jack(s) 2
Back S/PDIF Output Port(s) 1
Back Other Port(s) 2 x antenna connectors (2T2R)
Back Button(s) 1 x Q-Flash Plus
24-pin ATX Power 1
8-pin ATX Power 1
USB 2.0 Header(s) 2
USB 3.2 Header(s) Gen 1 2
Front Panel Audio Connector 1
Internal Other Port(s) 3 x addressable RGB Gen2 LED strip headers‚1 x RGB LED strip header
Form Factor Standard ATX
Product Width 244mm
Product Length 305mm
Special Features AMD Socket AM4: Supports AMD Ryzen 5000 / 4000 / 3000 Series Processors.‚Hybrid Digital twin 8+2 phases VRM solution.‚Dual Channel DDR4: 4 x DIMMs with EXPO Memory Module Support.‚WIFI EZ-Plug: Quick and easy design for Wi-Fi antenna installation.‚PCIe EZ-Latch: PCIe slot with Quick Release & Screwless Design.‚M.2 EZ-Latch Plus/ Click: M.2 slots and heatsinks with screwless design.‚Ultra-Fast Storage: 2*M.2 slots, including PCIe 4.0 x4.‚Efficient Thermal: VRM Thermal Armor Advanced and M.2 Thermal Guard.‚Fast Networking: 2.5GbE LAN and Wi-Fi 7.‚Extended Connectivity: HDMI, Displayport.
Keywords Motherboard‚AM4‚DDR4
Warranty

New items carry the manufacturer's warranty where applicable.

Components returned for warranty must be in original condition and packaging where reasonable.

Warranty remedies are repair, replacement or refund. It does not cover accidental or liquid damage, power surges, or faults caused by software the customer installed. Full details are in our Terms & conditions (sections 5 and 9).

Collection & delivery

Collection and delivery

  • Collect from our shop: 53 Tunnel Hill, Worcester WR4 9SD, open seven days a week.
  • Delivery: please call us on 01905 673738 to arrange it. Delivery times are estimates.
  • Payment is made in full by the methods we accept before collection or delivery.
